EBS820
TIME & ATTENDANCE l ACCESS CONTROL
FOR INTERNAL & EXTERNAL USE
The EBS820 outdoor fingerprint terminal provides comprehensive Access Control and Time & Attendance. It boasts the latest fingerprint algorithm coupled with the world’s best fingerprint sensor. Packed in a rugged IP67 housing, with multi-class RFID reading technology.
The device comes with a TCP/IP interface, RS-485 and Wiegand to provide higher flexibility and multiple installation options for different environments. It also offers 2 internal inputs and 1 internal relay output to control peripheral devices.
• Fast fingerprint matching speed
• Ideal for outdoor installations
• Supports most types of RFID card standards with a single device
• Advanced accuracy and security – High-precision OP6 optical sensor
| SPECIFICATIONS | |
|---|---|
RF Options | 125kHz EM & 13.56MHz MIFARE,
MIFARE Plus, DESFire EV1/EV2*, FeliCa,
NFC & 2.4GHz BLE |
Sensor Type | Optical Sensor (OP6) |
Extractor / Matcher | MINEX certified and compliant |
CPU | 1.2 GHz |
Memory | 4GB Flash + 64MB RAM |
Template Count | User: 10,000 l Template: 20,000 (Two templates per finger) l Logs: 1,000,000 |
LCD | 1.77” color LCD |
Sound | 16-bit Hi-Fi |
Ethernet | 10/100 Mbps, auto MDI/MDI-X |
RS-485 | 1ch Host or Slave (Selectable) |
Wiegand | 1ch Input or Output (Selectable) |
TTL | 2ch Input |
Relay | 1 Relay |
Ingress Protection | IP67 |
Power | DC 12V |
Operating Temperature | -20°C ~ 50°C, (BLN2-PAB: -10°C ~ 50°C) |
Operating Humidity | 0% ~ 80%, non-condensing |
Dimensions (WxHxD) | 58 x 190 x 44 mm |
Certificates | CE, FCC, RoHS, REACH, WEEE, FBI PIV (BLN2-PAB sensor only) |
